H=0.61in. (15.5mm.

Pickering Single in Line Reed SERIES 118 Portable Instrumentation • High coil resistance - 5 volt coil up to 2200 Ohms • Small board area 0.2 x 0.33 inches (5.08 x 8.38mm) • 10 watts or 15 watts rating Dimensions 1A L=0.33in. (8.38mm.) W=0.21in. (5.08mm.) H=0.61in. (15.5mm.) SERIES 117 Very High Density Instrumentation & ATE • Smallest board area. 1A version requires 0.15 x 0.27 inches (3.8mm x 6.8mm) • 1 or 2 switches with 3 Watts rating • 5 Volt coils with optional diode Dimensions 1A L=0.26in. (6.6mm.) W=0.145in. (3.7mm.) H=0.385in. (9.8mm.) SERIES 116 Very High Density Instrumentation & ATE • Smallest board area. 1A version requires 0.15 x 0.27 inches .(3.8mm x 6.8mm) • 1 or 2 switches with 10 Watts rating • 5 or 12 Volt coils with optional diode Dimensions 1A L=0.26in. (6.6mm.) W=0.145in. (3.7mm.) H=0.49in. (12.45mm.) SERIES 115 Very High Density Instrumentation & ATE • Smallest board area. 0.15 x 0.27 inches .(3.8mm x 6.8mm) • Up to 15 Watts, 0.75 Amps rating • 5 or 12 Volt coils with optional diode Dimensions 1A L=0.26in. (6.6mm.) W=0.145in. (3.7mm.) H=0.61in. (15.5mm.) SERIES 114 High Power Switching - Up to 40 watts • Will replace mercury wetted relays in some applications • 1 Amp switching, 2 Amps carry • AC Mains voltage switch Dimensions 1A L=0.95in. (24.1mm.) W=0.245in. (6.3mm.) H=0.32in. (8.1mm.) SERIES 113 High Density Instrumentation & ATE • Requires small area of only 0.15 x 0.5 inches (3.8mm x 12.5mm) • 10 Watts Form or 3 Watts Form C switches • Smallest Form C reed relay Dimensions 1A 1C L=0.49in. (12.5mm.) W=0.145in. (3.7mm.) H=0.26in. (6.6mm.) SERIES 112 High Density Instrumentation & ATE • Requires broad area of only 0.15 x 0.4 inches (3.8mm x 10.2mm) • Pins on 0.1 inch pitch - Compatible with Pickering Series 110 & 111 • 10 Watts switch Dimensions L=0.39in. (10mm.) W=0.145in. (3.7mm.) H=0.43in. (11mm.) SERIES 111 & 111P High Density Instrumentation & ATE • Requires board area of only 0.15 x 0.4 inches (3.8mm x 10.2mm) • Pins on 0.1 inch pitch as 110 & 112 • 3 Watts switch in Mu-metal or Plastic package (not illustrated) Dimensions all types L=0.39in. (10mm.) W=0.145in. (3.7mm.) H=0.26in. (6.6mm.) SERIES 110 High Density Instrumentation & ATE • Requires board area of only 0.15 x 0.4 inches (3.8mm x 10.2mm) • Pins on 0.1 inch pitch - Compatible with Pickering Series 111 & 112 • 10 Watts switch L=0.39in. (10.mm.) W=0.145in. (3.7mm.) H=0.6in. (15.0mm.) SERIES 109 & 109P High Density Instrumentation & ATE • Requires board area of only 0.15 x 0.6 inches (3.8mm x 15.2mm) • 10 Watts switches in Mu-metal or Plastic package Dimensions 1ACoax L=0.595in. (15.1.mm.) W=0.145in. (3.7mm.) H=0.26in. (6.6mm.) SERIES 108 Instrumentation & ATE • Requires board area of 0.15 x 0.8 inches (3.8mm x 20.3mm) • 10 Watts Form or 3 Watts Form C switches in Mu-metal package Dimensions 1A 1C L=0.79in. (20.1mm.) W=0.145in. (3.7mm.) H=0.26in. (6.6mm.) SERIES 107 Instrumentation & ATE • Requires board area of 0.2 x 0.8 inches (5.1mm x 20.3mm) • Dry or Mercury Wetted switches in patented Mu-metal package • Unique 2 Form C SIL relay Dimensions 1A 1C L=0.75in. (19.1mm.) W=0.19in. (4.8mm.) H=0.30in. (7.6mm.) SERIES 106 Instrumentation & ATE • Requires board area of 0.2 x 0.8 inches (5.1mm x 20.3mm) • 10 Watts Form or 3 Watts Form C switches Dimensions all types L=0.75in. (19.1mm.) W=0.19in. (4.8mm.) H=0.32in. (8.1mm.) SERIES 105 Instrumentation & ATE • Requires board area of 0.27 x 0.8 inches (6.8mm x 20.3mm) • Dry or Mercury Wetted switches Dimensions 1A 1C L=0.75in. (19.1mm.) W=0.26in. (6.6mm.) H=0.32in. (8.1mm.) SERIES 104 High Voltage - Up to 3kV • Requires board area of 0.25 x 1.0 inches (6.4mm x 25.4mm) • Ideal for Cable Test ATE • Dry or Mercury Wetted switches Dimensions 1A L=0.95in. (24.1mm.) W=0.246in. (6.3mm.) H=0.32in. (8.1mm.) SERIES 103 Low Capacitance • Requires board area of 0.25 x 1.0 inches (6.4mm x 25.4mm) • Form with one fifth the usual switch to coil capacitance • Coaxial guarded version Dimensions all types L=0.75in. (19.1mm.) W=0.19in. (4.8mm.) H=0.32in. (8.1mm.) SERIES 102 RF Switching • 50 Ohms Independence - Mu-metal SIL package or plastic flatpack • SIL - Up to 1.5 GHz • Flatpack - Up to 3 GHz Dimensions 1ACoax L=0.75in. (19,1.mm.) W=0.19in. (4.8mm.) H=0.30in. (7.6mm.) SERIES 101 Direct Drive From 74 HC or HCT Logic • 5 Volt coil for 1A dry version is 1600 0r 3000 Ohms • Dry or Mercury Wetted switches Dimensions 1A 1C L=0.79in. (20.1mm.) W=0.29in. (7.4mm.) H=0.37in. (9.4mm.) SERIES 100 Low Thermal EMF • Ideal for data acquisition - Typical Thermal EMF of 1 microvolt or less • 5 Volt coil for 1A or 1C dry version is 3300 Ohms (2700 Ohms for 2A) • Dry or Mercury Wetted switches Dimensions 1A 1C L=0.95in. (24.1mm.) W=0.4in. (10.2mm.) H=0.5in. (12.7mm.) Pickering Dual in Line Reed Relays SERIES 97 Standard DIL Reed Relays • Wide range featuring dry or mercury wetted switches • 5 Pickering Electronics ürünlerini satın almak için İmaj Teknik ile iletişime geçebilir detaylı bilgi ve fiyatları öğrenebilirsiniz
