SPECIFICATIONS Brass rings. Rotor unit rotating on ball bearing. Available with self-extinguishing thermoplastic protection or without protection and support plates (only rings and brushes). Further information available on the technical documentation PRCA0EAG00. TECHNICAL CHARACTERISTICS Operational temperature -25°C / +70°C Degree of protection IP 40 Insulation category Class I Rated operational current 50A Rated operational voltage 400 Vac Markings CE Standard Codes and Dimensions Collectors with protection No. 50A Code rings 3 PF2203P001 4 PF2204P001 5 PF2205P001 6 PF2206P001 7 PF2207P001 8 PF2208P001 9 PF2209P003 10 PF2210P001 11 PF2211P002 12 PF2212P001 13 PF2213P001 14 PF2214P001 15 PF2215P001 16 PF2216P001 Max. No. of rings: 16 Collectors without protection No. 50A Code rings 3 PF2203N001 4 PF2204N001 5 PF2205N001 6 PF2206N001 7 PF2207N001 8 PF2208N001 9 PF2209N001 10 PF2210N001 11 PF2211N001 12 PF2212N002 13 PF2213N001 14 PF2214N002 15 PF2215N001 16 PF2216N002 Max. No. of rings: 16 ,50A Slip ring collector specıfıcatıons brass rings. rotor unit rotating on ball bearing. available with self-extinguishing thermoplastic…,,54,1,0,50a-slip-ring-collector,2014-12-04 01:10:00
